11 Comments

Nice work, the finished knob ls good looking, and with this method I can make larger knobs for ease of use by my aging hands.
nice, good way to do it.

Ron


Oldtool
Nice work, the finished knob ls good looking, and with this method I can make larger knobs for ease of use by my aging hands.

I've made many using this simple method. You're right. Easy to make and easy on the hands using it.

987Ron
nice, good way to do it.

Thanks Ron!
Nice quick knobs!! Do you epoxy the head into the wood?

Cheers, Jim ........................ Variety is the spice of life...............Learn something new every day

Jim Jakosh
Nice quick knobs!! Do you epoxy the head into the wood?

Yes Jim ... as per my first indent above....

* ...... After checking the fit, I remove and epoxy in the bolt.
Cheers!
I do something similar but before using the hole saw, I often cut 3, 4 or even more smaller holes, depending upon the size and shape desired, around the perimeter to create notched knobs.  Handy when you need a little more grip.  3 larger holes will give you sort of a 3 wing knob and  5 or more small holes give you one sort of with detentes around the perimeter.

--Nathan, TX. Hire the lazy man. He may not do as much work but that's because he will find a better way.

By the way, here is a little pro tip that I picked somewhere online when using a hole saw in general.  A couple of relief holes around the perimeter (waste side) of where the hole saw is cutting will often result in cleaner holes and easier cutting.  If you are cutting for a hole, the relief holes are just inside the perimeter.  If cutting disks, just outside.  You want the relief hole to just make contact with the waste side of the cut. The bigger the hole saw the more relief hole to pre-drill.  Usually 1 to 3 1/4" holes are enough.  Since hole saws do not pull saw dust out of the kerf very well, especially on really thick pieces, the hole gives the saw dust a place to go and makes for cleaner cuts with less chance of burning or just overheating the hole saw which can ruin them.  I have found that the cuts go twice a fast when I take the time to do this.

--Nathan, TX. Hire the lazy man. He may not do as much work but that's because he will find a better way.


Lazyman
I do something similar but before using the hole saw, I often cut 3, 4 or even more smaller holes, depending upon the size and shape desired, around the perimeter to create notched knobs.  Handy when you need a little more grip.  3 larger holes will give you sort of a 3 wing knob and  5 or more small holes give you one sort of with detentes around the perimeter.

Lazyman ... I do that too. I make many kinds of knobs. I have a few step and repeat jigs I made as well. This is just a quick and simple way that actually functions well.
Thanks Lazyman. That tip works well. It keeps the teeth from binding up with sawdust. Good on ya!
Here's one of my step and repeat jigs for making multiple types of knobs
